A-A-59001A(SH)
TABLE I. Two-ply batterboard standard sizes and estimated weights.
Two-Ply
Actual Size 1/
Panel Type
Nominal Size
Estimated Weight
17 in × 71 in × 3½ in
111.3 lb
A
1½ ft × 6 ft
(432 mm × 1804 mm × 89 mm)
(50.5 kg)
35 in × 71 in × 3½ in
229.9 lb
B
3 ft × 6 ft
(889 mm × 1804 mm × 89 mm)
(104.2 kg)
35 in × 47 in × 3½ in
152.4 lb
C
3 ft × 4 ft
(889 mm × 1194 mm × 89 mm)
(69.1 kg)
47 in × 47 in × 3½ in
208.3 lb
D
4 ft × 4 ft
(1194 mm × 1194 mm × 89 mm)
(94.5 kg)
35 in × 95 in × 3½ in
307.2 lb
E
3 ft × 8 ft
(889 mm × 2414 mm × 89 mm)
(139.3 kg)
47 in × 95 in × 3½ in
420.1 lb
F
4 ft × 8 ft
(1194 mm × 2414 mm × 89 mm)
(190.6 kg)
FOOTNOTES:
1/
Panels are to be manufactured to tolerances shown in the manufacturing detail on the
fabrication drawings.
NOTES:
1.
Other non-standard sizes are permitted if they are needed to replace missing or
damaged panels on earlier ships which may have preceded this CID or
standardization of the batterboard panel sizes.
2.
Three-ply panels shall not be used for new ship construction and are only intended
for replacement of existing like panels.
3.
Two-ply construction is the preferred panel design and is an acceptable alternative
replacement for 3-ply provided that the proper length of attachment stud is being
used or can be replaced.
4.
Panel weights shown in tables are estimated. Actual panel weights may vary.
3
