A-A-59001A(SH)
TABLE III. Lightweight batterboard sizes and estimated weights.
Light Weight
(2.5-inch thick)
Actual Size 1/
Panel Type
Nominal Size
Estimated
Weight
17 in × 71 in × 2½ in
69.8 lb
A
1½ ft × 6 ft
(432 mm × 1804 mm × 64 mm)
(31.7 kg)
35 in × 71 in × 2½ in
145.5 lb
B
3 ft × 6 ft
(889 mm × 1804 mm × 64 mm)
(66.0 kg)
35 in × 47 in × 2½ in
96.5 lb
C
3 ft × 4 ft
(889 mm × 1194 mm × 64 mm)
(43.8 kg)
47 in × 47 in × 2½ in
131.1 lb
D
4 ft × 4 ft
(1194 mm × 1194 mm × 64 mm)
(59.5 kg)
35 in × 95 in × 2½ in
194.7 lb
E
3 ft × 8 ft
(889 mm × 2414 mm × 64 mm)
(88.3 kg)
47 in × 95 in × 2½ in
264.6 lb
F
4 ft × 8 ft
(1194 mm × 2414 mm × 64 mm)
(120.0 kg)
FOOTNOTES:
1/
Panels are to be manufactured to tolerances shown in the manufacturing detail on
the fabrication drawings.
NOTES:
1.
Other non-standard sizes are permitted if they are needed to replace missing or
damaged panels on earlier ships which may have preceded this CID or
standardization of the batterboard panel sizes.
2.
Three-ply panels shall not be used for new ship construction and are only intended
for replacement of existing like panels.
3.
Two-ply construction is the preferred panel design and is an acceptable alternative
replacement for 3-ply provided that the proper length of attachment stud is being
used or can be replaced.
4.
Panel weights shown in tables are estimated. Actual panel weights may vary.
2.4 Batterboard planks. Synthetic batterboard planks are 2-ply constructed and partially backed up with elastomeric
(similar to batterboards) (see figure 1) and shall be provided in standard plank size 7.5- by 189.5- by 3.5-inch long
planks, or other lengths as required, in order to replace the standard size wood batterboard planks or as specified on
installation drawings. There is one standard cross-sectional size synthetic batterboard plank available for use on
amphibious ships but the overall length may vary with each ship class. The corresponding estimated weight range
for the standard size synthetic batterboard plank is specified in table IV.
5
