MIL-PRF-0032482(SH)
This specification is approved for interim use by the Commander, Naval Sea Systems Command (NAVSEA).
1. SCOPE
1.1 Scope. This specification covers quick-acting watertight doors (QAWTD) with a 26- by 66-inch clear
opening for use in internal shipboard watertight boundaries where ingress and egress are required through interior,
structural bulkheads.
1.2 Classification. QAWTDs are of the following pressure ratings, configurations, and dimensions.
1.2.1 Pressure rating. QAWTDs are designed to have a tightness pressure of either:
a.
Pressure Rating A: 5 pounds per square inch (psi)
b.
Pressure Rating B: 10 psi
c.
Pressure Rating C: 15 psi
1.2.2 Configuration (operation). QAWTDs are of the following configurations as classified by operator
orientation:
a.
Operation 1: Left-Hand Operation
b.
Operation 2: Right-Hand Operation
1.2.3 Dimension. QAWTDs have the following clear opening:
a.
Clear Opening: 26- by 66-inch
1.3 Part or identifying number (PIN). PINs to be used for QAWTDs acquired to this specification are created
as follows (see 6.2):
M
0032482
-
X
X
X
Prefix for Military
Specification
Pressure Rating (psi)
Configuration
Dimension
Specification
Number
(Operation)
A: 5
A: Clear Opening* (CO)
B: 10
1: Left-hand
26" × 66"
C: 15
2: Right-hand
(see 1.2.3)
(see 1.2.1)
(see 1.2.2)
Examples:
M0032482-A1A
5 psi, left-hand operation, CO 26" × 66"
M0032482-C2A
15 psi, right-hand operation, CO 26" × 66"
M0032482-B1A
10 psi, left-hand operation, CO 26" × 66"
*Clear Opening: The nominal unobstructed access opening of the frame, neglecting minor intrusions such as the
corner fillets of some rectangular frames.
