MIL-PRF-0032482(SH)
4. VERIFICATION
4.1 Classification of inspections. The inspection requirements specified herein are classified as follows:
a.
b.
4.2 Qualification inspection. Qualification inspection shall be conducted on a sufficient number of QAWTDs
containing a fixed light assembly and shall include the examination of 4.4 and the tests of 4.5 through 4.6.5 (see
table II).
4.2.1 Test facility. Qualification inspection shall be conducted at a certified independent test facility.
4.2.2 Test tank. A test tank shall be designed to represent a shipboard bulkhead installation of a QAWTD. A
QAWTD shall be installed onto the test tank using a 3/8-inch mounting plate that simulates the stiffness of a bulkhead
located on a Navy ship. The test tank shall have fittings to provide for filling, loading, unloading, and pressure
measurement.
4.3 Conformance inspection. Conformance inspection shall include the examination of 4.4 and the test of 4.6.1
(see table II).
TABLE II. Examinations and inspections.
Test
Verification
Requirement Paragraph
Qualification
Conformance
Requirement
Paragraph
Examination
X
X
Operational
X
X
Hydrostatic
X
Reliability
X
Shock
X
Vibration
X
4.4 Examination. Each QAWTD shall be examined for compliance with the requirements specified in
section 3. Any redesign or modification of the contractor s standard product to comply with specified requirements,
or any necessary redesign or modification following failure to meet the specified requirements, shall receive
particular attention for adequacy and suitability. This element of inspection shall encompass all visual examinations
and dimensional requirements. Non-compliance with any specified requirement shall constitute cause for rejection.
4.5 Classification of defects. Compliance shall be determined by examination for the defects listed in table III.
Non-compliance with any specified requirement shall constitute cause for rejection.
6
