MIL-PRF-0032482(SH)
TABLE III. Classification of defects.
Method of
Category
Defect
Examination
Major
Dimensions affecting interchangeability,
SIE 1/
101
out of tolerance
Failure to meet any test acceptance
As specified
102
criteria
(see 4.6)
Minor
Dimensions not affecting
201
SIE
interchangeability, out of tolerance
Nonconformance in design or
202
Visual and SIE
construction
203
Weight not as specified
SIE
204
Improper finish, color, or application
Visual
205
Improper marking or identification plates
Visual
Logistics support documentation
206
Visual
inaccurate or incomplete
NOTE:
1/
SIE = Standard Inspection Equipment
4.6 Performance.
4.6.1 Operational test. Each QAWTD shall be operationally tested to verify the requirements as specified in
table II. The panel shall be opened to the maximum door swing angle (see 3.4.7.1) from a closed and dogged
position. The force to open the door shall be measured perpendicular to the door panel. This opening force shall not
exceed the specified value. The panel shall then be closed and dogged. The transition from fully open to the closed
and latched position shall be smooth with no perceivable binding. Failure to meet the requirements of this test shall
be cause for rejection.
4.6.2 Hydrostatic test. The hydrostatic test shall be comprised of the following and shall be accomplished in
the following order.
4.6.2.1 Design test. The design test shall be comprised of the following.
4.6.2.1.1 Design pressure test. A QAWTD assembly shall be tested to 100 percent of its design pressure on
both the internal and external sides of the panel. The QAWTD assembly shall not allow any passage of water during
the hydrostatic test as it is pressurized up to and including the design pressure. Design pressure shall be held for
10 minutes. Failure to meet the requirements of this test shall be cause for rejection.
4.6.2.1.2 Design operational test. Each QAWTD shall be operationally tested to verify the requirements as
specified in table II. The panel shall be opened to the maximum door swing angle (see 3.4.7.1) from a closed and
dogged position. The force to open the door shall be measured perpendicular to the door panel. This opening force
shall not exceed the specified value. The panel shall then be closed and dogged. The transition from fully open to
the closed and latched position shall be smooth with no perceivable binding. Failure to meet the requirements of
this test shall be cause for rejection.
7
