MIL-DTL-613D
TABLE VI. Types of defects.
No.
Defects
1
Type and size not as specified.
2
Material not as specified; evidence of laps, seams, pipes, flaws, cracks, scale, fins, porosity,
hard spots or nonmetallic inclusions and segregations.
3
Welding when applicable, nonconforming; surface not smooth, evidence of incomplete fusion,
nonmetallic inclusions or cracks.
4
Grapnel construction and fabrication not as specified, prong point damaged or
nonconforming, number of prongs not as required, dimensions not within required limits.
5
Eye for trip wire when applicable, not as specified, missing, damaged or not secured to base
as required.
6
Shackle and pin when required, missing, damaged or inoperable, type and class not as
specified (type I only).
7
Thimble for eye at head missing or damaged, type and size not as specified (type II only).
8
Chain missing, damaged or not secured as required, type and grade not as specified,
connecting links missing, damaged or nonconforming (type II sizes 3 and 4 only).
9
Thimble (as applicable) at chain end missing or damaged, type and size not as specified.
10
Wire rope missing, damaged or not attached as specified, type, size and length not as
required, not coated to prevent corrosion when specified (type IV only).
11
Thimbles to secure wire rope ends not type and size as specified (type IV only
12
Eye splices for rope thimbles not wormed and served as required, when applicable (type IV
size 1 only).
13
Wire rope clips when applicable, not size specified, damaged, not located and secured as
required (type IV only).
14
Eye hook at free end of rope, missing, damaged or nonconforming; material, type and size
not as specified (type IV size 1 only).
15
Ring at free end of rope missing, damaged or nonconforming; material and dimensions not as
specified (type IV size 2 only).
16
Grapnel and all attachments (except type III when not specified) not coated to prevent
corrosions, coating nonconforming, not adherent, smooth or uniform, not free from uncoated
spots, injurious lumps, pits, blisters, acid and black spots, dross and flux.
17
Eye hook at free end of rope, missing, damaged or nonconforming; material, type and size
not as specified (type IV size 1 only).
18
Ring at free end of rope missing, damaged or nonconforming; material and dimensions not as
specified (type IV size 2 only).
19
Grapnel and all attachments (except type III when not specified) not coated to prevent
corrosions, coating nonconforming, not adherent, smooth or uniform, not free from uncoated
spots, injurious lumps, pits, blisters, acid and black spots, dross and flux.
20
Marking "U.S.", manufacturer's identification, (weight, type I only) missing, incorrect, illegible
or not permanent.
21
Marking for Nonmagnetic grapnels not permanently marked with the letters "N-M".
22
Varnish color not as specified in 3.5.3.2.
11
